CE Certified Hot-Dip Galvanized Steel Light Pole

Short Description:

Hot-Dip Galvanized Steel Light Pole has become an indispensable and important component of urban lighting facilities due to its strong corrosion resistance, high durability, beautiful appearance, and high-quality material selection.

Place of Origin: Jiangsu, China

Material: Steel, Metal

Type: Single Arm

Shape: Round, Octagonal, Dodecagonal or Customized

Application: Street light, Garden light, Highway light or Etc.

MOQ: 1 Set

Send email to us

DOWNLOAD
RESOURCES

Product Detail

Product Tags

Description

Our CE Certified Hot-Dip Galvanized Steel Light Pole is relatively durable and can withstand large external forces. It is suitable for large places such as highways and airports, and has good corrosion resistance and rust prevention properties.

Technical Data

Product Name	Outdoor Hot Dip Galvanized Driveway Light Pole
Material	Commonly Q345B/A572, Q235B/A36, Q460 ,ASTM573 GR65, GR50 ,SS400, SS490, ST52
Height	5M	6M	7M	8M	9M	10M	12M
Dimensions(d/D)	60mm/150mm	70mm/150mm	70mm/170mm	80mm/180mm	80mm/190mm	85mm/200mm	90mm/210mm
Thickness	3.0mm	3.0mm	3.0mm	3.5mm	3.75mm	4.0mm	4.5mm
Flange	260mm*14mm	280mm*16mm	300mm*16mm	320mm*18mm	350mm*18mm	400mm*20mm	450mm*20mm
Tolerance of dimension	±2/%
Minimum yield strength	285Mpa
Max ultimate tensile strength	415Mpa
Anti-corrosion performance	Class II
Against earthquake grade	10
Color	Customized
Surface treatment	Hot-dip Galvanized and Electrostatic Spraying, Rust Proof, Anti-corrosion performance Class II
Shape Type	Conical pole, Octagonal pole,Square pole, Diameter pole
Arm Type	Customized: single arm,double arms,triple arms,four arms
Stiffener	With big size to strength the pole to resist the wind
Powder coating	Thickness of powder coating>100um.Pure polyester plastic powder coating is stable, and with strong adhesion & strong ultraviolet ray resistance.Film thickness is more than 100 um and with strong adhesion. The surface is not peeling even with blade scratch (15×6 mm square).
Wind Resistance	According to local weather condition, General design strength of wind resistance is ≥150KM/H
Welding Standard	No crack, no leakage welding, no bite edge, weld smooth level off without the concavo-convex fluctuation or any welding defects.
Hot-Dip Galvanized	Thickness of hot-galvanized>80um.Hot Dip Inside and outside surface anti-corrosion treatment by hot dipping acid. which is in accord with BS EN ISO1461 or GB/T13912-92 standard. Designed life of pole is more than 25 years, and the galvanized surface is smooth and with the same color. Flake peeling hasn't been seen after maul test.
Anchor bolts	Optional
Material	Aluminium,SS304 is available
Passivation	Available
