5-12m Black Pole for Street Light
DOWNLOAD
RESOURCES
Description
Black pole is made of high-quality Q235 steel pipe, with a smooth and beautiful surface; The main pole diameter is made of circular tubes with corresponding diameters according to the height of the lamp post.
Technical Data
| Product Name | 5-12m Black Pole for Street Light | ||||||
| Material | Commonly Q345B/A572, Q235B/A36, Q460 ,ASTM573 GR65, GR50 ,SS400, SS490, ST52 | ||||||
| Height | 5M | 6M | 7M | 8M | 9M | 10M | 12M |
| Dimensions(d/D) | 60mm/150mm | 70mm/150mm | 70mm/170mm | 80mm/180mm | 80mm/190mm | 85mm/200mm | 90mm/210mm |
| Thickness | 3.0mm | 3.0mm | 3.0mm | 3.5mm | 3.75mm | 4.0mm | 4.5mm |
| Flange | 260mm*14mm | 280mm*16mm | 300mm*16mm | 320mm*18mm | 350mm*18mm | 400mm*20mm | 450mm*20mm |
| Tolerance of dimension | ±2/% | ||||||
| Minimum yield strength | 285Mpa | ||||||
| Max ultimate tensile strength | 415Mpa | ||||||
| Anti-corrosion performance | Class II | ||||||
| Against earthquake grade | 10 | ||||||
| Shape Type | Conical pole, Octagonal pole,Square pole, Diameter pole | ||||||
| Stiffener | With big size to strength the pole to resist the wind | ||||||
| Wind Resistance | According to local weather condition, General design strength of wind resistance is ≥150KM/H | ||||||
| Welding Standard | No crack, no leakage welding, no bite edge, weld smooth level off without the concavo-convex fluctuation or any welding defects. | ||||||
| Anchor bolts | Optional | ||||||
| Passivation | Available | ||||||
Project Presentation
Our Exhibition
Our Certifications
Our Certifications
1. Q: Are you a trading company or a manufacturer?
A: Our company is a very professional and technical manufacturer of light pole products. We have more competitive prices and the best after-sales service. In addition, we also provide customized services to meet the needs of customers.
2. Q: Can you deliver on time?
A: Yes, no matter how the price changes, we guarantee to provide the best quality products and timely delivery. Integrity is the purpose of our company.
3. Q: How can I get your quotation as soon as possible?
A: Email and fax will be checked within 24 hours and will be online within 24 hours. Please tell us the order information, quantity, specifications (steel type, material, size), and destination port, and you will get the latest price.
4. Q: What if I need samples?
A: If you need samples, we will provide samples, but the freight will be borne by the customer. If we cooperate, our company will bear the freight.
