25ft Street Light Pole for Street Lighting

Short Description:

Our 25ft street light pole is designed to provide efficient and reliable lighting for urban areas, commercial complexes, highways and other large outdoor areas. It can withstand harsh weather conditions and is ideal for illuminating large areas with bright, consistent light.


  • facebook (2)
  • youtube (1)

DOWNLOAD
RESOURCES

Product Detail

Product Tags

Street Light Pole for Street Lighting

Product Description

Standing 25 feet tall, this light pole features durable construction and high-quality materials to ensure it is durable and resilient in any environment. Its sleek, modern design makes it ideal for urban landscapes, while its high-quality construction ensures optimum performance and longevity even in harsh weather conditions.

The 25ft street light pole is designed to provide a high level of lighting efficiency with minimal glare, making it ideal for illuminating pedestrian crossings, parks and commercial buildings. Light poles provide evenly distributed light directed towards busy areas to improve visibility while reducing energy consumption.

Made from high-quality materials, this street light pole is rust, corrosion and UV resistant, meaning it can withstand the most challenging weather conditions, from extreme heat to freezing cold. Whether it's rain, wind or snow, this pole will stand the test of time.

The 25ft street light pole is powered by LED lamps, which is very energy-saving and environmentally friendly. It provides high quality light output while consuming a fraction of the energy required by traditional halogen bulbs, helping to reduce energy costs while providing excellent lighting coverage.

In addition to its strong and durable construction, the 25' Light Pole is easy to install and maintain. It requires minimal maintenance, which means it is ideal for large commercial areas and urban landscapes, where regular maintenance can be challenging.

In conclusion, if you are looking for reliable, high-quality, energy-efficient street light poles for cityscapes, commercial complexes, highways, and other large outdoor areas, you can't go wrong with 25ft street light pole. Its sleek design, high-quality materials and efficient lighting features make it a valuable addition to any venue where safety and visibility are important. Upgrade your outdoor lighting today and experience the difference with our newest products.

Technical Data

Material Commonly Q345B/A572, Q235B/A36, Q460 ,ASTM573 GR65, GR50 ,SS400, SS490, ST52
Height 5M 6M 7M 8M 9M 10M 12M
Dimensions(d/D) 60mm/150mm 70mm/150mm 70mm/170mm 80mm/180mm 80mm/190mm 85mm/200mm 90mm/210mm
Thickness 3.0mm 3.0mm 3.0mm 3.5mm 3.75mm 4.0mm 4.5mm
Flange 260mm*14mm 280mm*16mm 300mm*16mm 320mm*18mm 350mm*18mm 400mm*20mm 450mm*20mm
Tolerance of dimension ±2/%
Minimum yield strength 285Mpa
Max ultimate tensile strength 415Mpa
Anti-corrosion performance Class II
Against earthquake grade 10
Color Customized
Surface treatment Hot-dip Galvanized and Electrostatic Spraying, Rust Proof, Anti-corrosion performance Class II
Shape Type Conical pole, Octagonal pole,Square pole, Diameter pole
Arm Type Customized: single arm,double arms,triple arms,four arms
Stiffener With big size to strength the pole to resist the wind
Powder coating Thickness of powder coating is 60-100um.Pure polyester plastic powder coating is stable, and with strong adhesion & strong ultraviolet ray resistance. The surface is not peeling even with blade scratch (15×6 mm square).
Wind Resistance According to local weather condition, General design strength of wind resistance is ≥150KM/H
Welding Standard No crack, no leakage welding, no bite edge, weld smooth level off without the concavo-convex fluctuation or any welding defects.
Hot-Dip Galvanized Thickness of hot-galvanized is 60-100um. Hot Dip Inside and outside surface anti-corrosion treatment by hot dipping acid. which is in accord with BS EN ISO1461 or GB/T13912-92 standard. Designed life of pole is more than 25 years, and the galvanized surface is smooth and with the same color. Flake peeling hasn't been seen after maul test.
Anchor bolts Optional
Material Aluminium,SS304 is available
Passivation Available

Project Presentation

Project presentation

Exhibition

Exhibition

Certificate

Certificate

FAQ

1. Q: Are you a factory or trading company?

A: We are a factory.

In our company, we pride ourselves on being an established manufacturing facility. Our state-of-the-art factory has the latest machinery and equipment to ensure that we can provide our customers with the highest quality products. Drawing on years of industry expertise, we continually strive to deliver excellence and customer satisfaction.

2. Q: What's your main product?

A: Our main products are Solar Street Lights, Poles, LED Street Lights, Garden Lights and other customized products etc.

3. Q: How long is your lead time?

A: 5-7 working days for samples; around 15 working days for bulk order.

4. Q: What's your shipping way?

A: By air or sea ship are available.

5. Q: Do you have OEM/ODM service?

A: Yes.
Whether you are looking for custom orders, off-the-shelf products or custom solutions, we offer a wide range of products to meet your unique needs. From prototyping to series production, we handle every step of the manufacturing process in-house, ensuring we can maintain the highest standards of quality and consistency.
