250W/300W1 module | 500W/600W2 modules | 750W/900W3 modules | 1000W/1200W4 modules | 1250W/1500W5 modules | 1500W/1800W6 modules | 2000W/2400W8 modules | |
Lamp Bead Model |
30305050 | 30305050 | 30305050 | 30305050 | 30305050 | 30305050 | 30305050 |
Series-parallel Mode |
7 series and 48 parallel6 series and 16 parallel | ||||||
Shell Weight | 4.09KG | 6.49KG | 9.00KG | 11.35KG | 13.82KG | 16.25KG | 22.06KG |
Overall Lamp Size |
123*580*138 mm | 250*580*138 mm | 378*580*138 mm | 505*580*138 mm | 632*580*138 mm | 760*580*138 mm | 1013*580*138 mm |
Package Size | 605*225*160 mm | 605*310*160 mm | 605*455*160 mm | 605*580*160 mm | 715*605*160 mm | 840*605*160 mm | 910*605*160 mm |
Protection Grade |
IP65 | IP65 | IP65 | IP65 | IP65 | IP65 | IP65 |
Lens Angle | 20° 60° 90° | 20° 60° 90° | 20° 60° 90° | 20° 60° 90° | 20° 60° 90° | 20° 60° 90° | 20° 60° 90° |
